AC115

Rosslare 1 Door Network Controller with
Software


  • Single Door Networkable Controller - Max 8 Doors
  • In / Out 26Bit Wiegand Input for up to 2400 Users
  • PC Software with up to 8 Time Zones
  • 16VAC





Specifications
SPECIFICATIONS Each AC-115 supports a single door with power and
control for 2 readers (IN/OUT), a 1.2 A lock strike,
door monitor & REX input, and has a built-in backup
battery charger.

With the PC software (AS-115), the system works
seamlessly in online and offline modes. A 2000 event
offline FIFO history log is stored in non-volatile
memory that can be uploaded to the PC.

Up to eight controllers can be connected in a reliable
and proven RS-485 network that interfaces with the
PC software using one RS-232 to RS-485 converter.

It is compatible with a variety of Rosslares readers,
and third-party magnetic lock strikes to suit the
application with a Form C locks strike relay for failsafe or fail-secure installations.
Unique features include internal bell sounder
enabling doorbell, chime, and alarm sounds.

Manufacturer ROSSLARE
