ENFEHMEE1234R

EHMEE1234R Enforcer Systems E100/E200/E300/E400 Housing Mount Extender - 360 x 360 x 214 mm

The EHMEE1234R is an Enforcer housing mount extender for E100, E200, E300 and E400 CPM installations. The brochure confirms a 360 x 360 x 214 mm size, 1.60 kg weight, and suitability for E100CPM/MCU, E100CPM/SU, E200CPM/MCU, E200CPM/SU, E300CPM/MCU, E300CPM/SU, E400CPM/MCU and E400CPM/SU units.

It is used in wall-mount applications to help achieve the desired deployment angle and PIR detection coverage. The brochure states that the housing mount is secured to the installed extender with six supplied bolts, and that the design uses a 15 degree tilt angle to prevent the smoke curtain from being deployed directly along the wall.

Key Features

• Extender format supports wall-mounted CPM housing mount installations
• Confirmed suitability across selected E100 E200 E300 and E400 CPM master and sub units
• Designed to help achieve the required deployment angle and PIR detection coverage
• Six-bolt housing mount fixing supports a defined extender-to-mount installation method
• 15 degree tilt angle helps direct deployment away from the wall surface
