HAC-HDW2802T-Z-A-DP
SKU
HAC-HDW2802T-Z-A-DP
Dahua 8MP 4K Starlight Varifocal Turret Camera HAC-HDW2802T-Z-A-DP
- Starlight, 120dB True WDR, 3DNR
- Max. 4K resolution · HD/SD switchable
- Audio in interface, built-in mic
- 3.7-11mm motorized lens
- Max. IR length 60m, Smart IR
- IP67, AC24V/DC12V±30%
| Format | Label | Description | Type | Size | Download |
|---|---|---|---|---|---|
|
Manual | DH-HAC-HDW2802T-Z-A-DP_Users-Manual_20180110 | 2 MB | Download | |
|
|
Brochure | DH-HAC-HDW2802T-Z-A-DP_Datasheet | 618.8 KB | Download |
- Starlight, 120dB True WDR, 3DNR
- Max. 4K resolution
- Max. IR length 60m, Smart IR
Image Sensor
1/1.8" CMOS
Effective Pixels
3840(H)2160(V), 8MP
Scanning System
Progressive
Electronic Shutter Speed
PAL: 1/4s~1/100,000s
NTSC: 1/3s~1/100,000s
Minimum Illumination
0.005Lux/F1.5, 30IRE, 0Lux IR on
S/N Ratio
More than 65dB
IR Distance
Up to 60m (197eet)
IR On/Off Control
Auto / Manual
IR LEDs
2
Lens
Lens Type
Motorized lens / Fixed iris
Mount Type
Board-in
Focal Length
3.7-11mm
Max Aperture
F1.5
Angle of View
H: 112~46
Focus Control
Auto / Manual
Close Focus Distance
200mm
7.87''
Pan / Tilt / Rotation
Pan/Tilt/Rotation
Pan: 0 ~ 360
Tilt: 0 ~ 78
Rotation: 0 ~ 360
Video
Resolution
8MP (38402160)
Frame Rate
15fps@4K, 20fps@6MP, 25/30fps@4MP
Video Output
1-channel BNC high definition video output / CVBS video output (DIP switch)
Day/Night
Auto (ICR) / Manual
OSD Menu
Multi-language
BLC Mode
BLC / HLC / WDR
WDR
120dB
Gain Control
AGC
Noise Reduction
2D/3D
White Balance
Auto / Manual
Smart IR
Auto / Manual
DORI Distance
Note: The DORI distance is a general proximity of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.
DORI
Definition
Distance
Wide
Tele
Detect
25px/m (8px/ft)
83m(272ft)
190m(623ft)
Observe
63px/m (19px/ft)
33m(108ft)
76m(249ft)
Recognize
125px/m (38px/ft)
17m(56ft)
38m(125ft)
Identify
250px/m (76px/ft)
8m(26ft)
19m(62ft)
Certifications
Certifications
CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Interface
Audio Interface
1ch in & Built-in Mic
Eelectrical
Power Supply
AC 24V30% / DC 12V30%
Power Consumption
Max 12W ( IR on)
Environmental
Operating Conditions
-30C ~ +60C (-22F ~ +140F) / Less than 90% RH
* Start up should be done at above -30C (-22F)
Storage Conditions
-30C ~ +60C (-22F ~ +140F) / Less than 90% RH
Ingress Protection & Vandal Resistance
IP67
Construction
Casing
Aluminium
Dimensions
F122mm107mm (F4.8"4.2")
Net Weight
0.63kg (1.39lb)
Gross Weight
0.83kg (1.83lb)2492
1/1.8" CMOS
Effective Pixels
3840(H)2160(V), 8MP
Scanning System
Progressive
Electronic Shutter Speed
PAL: 1/4s~1/100,000s
NTSC: 1/3s~1/100,000s
Minimum Illumination
0.005Lux/F1.5, 30IRE, 0Lux IR on
S/N Ratio
More than 65dB
IR Distance
Up to 60m (197eet)
IR On/Off Control
Auto / Manual
IR LEDs
2
Lens
Lens Type
Motorized lens / Fixed iris
Mount Type
Board-in
Focal Length
3.7-11mm
Max Aperture
F1.5
Angle of View
H: 112~46
Focus Control
Auto / Manual
Close Focus Distance
200mm
7.87''
Pan / Tilt / Rotation
Pan/Tilt/Rotation
Pan: 0 ~ 360
Tilt: 0 ~ 78
Rotation: 0 ~ 360
Video
Resolution
8MP (38402160)
Frame Rate
15fps@4K, 20fps@6MP, 25/30fps@4MP
Video Output
1-channel BNC high definition video output / CVBS video output (DIP switch)
Day/Night
Auto (ICR) / Manual
OSD Menu
Multi-language
BLC Mode
BLC / HLC / WDR
WDR
120dB
Gain Control
AGC
Noise Reduction
2D/3D
White Balance
Auto / Manual
Smart IR
Auto / Manual
DORI Distance
Note: The DORI distance is a general proximity of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.
DORI
Definition
Distance
Wide
Tele
Detect
25px/m (8px/ft)
83m(272ft)
190m(623ft)
Observe
63px/m (19px/ft)
33m(108ft)
76m(249ft)
Recognize
125px/m (38px/ft)
17m(56ft)
38m(125ft)
Identify
250px/m (76px/ft)
8m(26ft)
19m(62ft)
Certifications
Certifications
CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Interface
Audio Interface
1ch in & Built-in Mic
Eelectrical
Power Supply
AC 24V30% / DC 12V30%
Power Consumption
Max 12W ( IR on)
Environmental
Operating Conditions
-30C ~ +60C (-22F ~ +140F) / Less than 90% RH
* Start up should be done at above -30C (-22F)
Storage Conditions
-30C ~ +60C (-22F ~ +140F) / Less than 90% RH
Ingress Protection & Vandal Resistance
IP67
Construction
Casing
Aluminium
Dimensions
F122mm107mm (F4.8"4.2")
Net Weight
0.63kg (1.39lb)
Gross Weight
0.83kg (1.83lb)2492
