TPC-BF1241-TB3F4-DW-S8-V1
TPC-BF1241-TB3F4-DW-S8-V1 Dahua Eureka Series Thermal Network Mini Hybrid Bullet Camera with Temperature Measurement - 3.5 mm Thermal and 4 mm Visible Lenses
The TPC-BF1241-TB3F4-DW-S8-V1 is a Dahua Eureka Series thermal network mini hybrid bullet camera that combines a 256 x 192 thermal channel with a 4 MP visible channel. This TB3F4 variant is listed with a 3.5 mm thermal lens and 4 mm visible lens, supported by a vanadium oxide uncooled focal plane detector, 1/1.8-inch progressive scan CMOS sensor, dual image fusion, 120 dB WDR and H.265/H.264/MJPEG video compression.
Built for short-distance monitoring, perimeter protection, heat/fire detection and temperature measurement, it supports low and high temperature modes from -20 °C to +650 °C with a specified maximum accuracy of 2 °C or 2%. AI functions, built-in dual microphones, local audio and light alarm prompts, PoE or wide DC power input, microSD edge storage, ONVIF/CGI/Dahua SDK interoperability and an IP67/IK10-rated housing support practical deployment in factories, car parks, villas and similar small to medium sites.
Key Features
- Hybrid thermal and visible imaging helps operators assess heat activity alongside visual scene detail
- Temperature-measurement capability supports monitoring across low and high temperature applications
- AI event functions help prioritise perimeter, behaviour and heat-related activity
- On-camera audio and light prompts provide clear local signalling when events are detected
- Network power, edge storage and rated housing support flexible deployment in exposed surveillance positions
