UPOE-2400G

24-Port Gigabit 802.3bt PoE++ Managed Injector Hub (800 watts)

PLANET’s newly-improved UPOE-2400G, a high-density, rack-mountable managed 802.3bt PoE++ Managed Injector Hub, features eight 10/100/1000BASE-T 90-watt 802.3bt type-4 PoE++ injector ports and sixteen 10/100/1000BASE-T 60-watt 802.3bt type-3 PoE++ injector ports with PLANET intelligent PoE functions through web user interface for remote management. With a total PoE budget of 800 watts, it delivers ultra PoE power over Ethernet UTP cables which allow data and power to transmit simultaneously to a remote 802.3bt/at powered device (PD).

Interface

• 48-port RJ45
- 24-port 10/100/1000Mbps “Data input”

- 24-port 10/100/1000Mbps “Data + Power output”

• One 10/100/1000BASE-T management port

802.3bt Power over Ethernet

• Complies with IEEE 802.3bt Power over Ethernet Plus Plus
• Backward compatible with IEEE 802.3at Power over Ethernet Plus
• Up to 24 ports of IEEE 802.3at/IEEE 802.3bt PoE devices powered
• 8 PoE ports with built-in 802.3bt type-4 PoE 90W or ultra PoE 95-watt injector function (Port-1 to Port-8)
• 16 PoE ports with built-in 802.3bt type-3 PoE 60W or ultra PoE 72-watt injector function (Port-9 to Port-24)
• All PoE ports support 802.3at end-span/mid-span PoE 36W injector function
• Auto detects powered device (PD)
• Circuit protection prevents power interference between ports
• Remote power feeding up to 100 meters

PoE Management

• Per port PoE power schedule
• PoE function enable/disable
• Per port PoE function enable/disable
• Per port PoE operation mode selection
• PoE port power feeding priority
• PD classification detection
• Over temperature protection
• PD alive check
• PoE schedule

Management

• Web interface for remote management
• Supports Network Time Protocol (NTP)
• Firmware upgrade through Web interface
• PLANET Smart Discovery utility automatically finds PLANET devices on the network
• SNMP v1, v2c and v3 for system status monitoring
• SNMP trap for alarm notification of events
• System log/remote syslog

Hardware

• 19-inch rack mountable; 1U height
• Reset button for resetting to default setting and system reboot
• LED indicators for PoE ready and PoE activity
• LED indicators for power alert and fan alert
